Tracking Device GPS Sensor

Tracking Device GPS Sensor Introduction：

The tracking device GPS sensor is a GPS vehicle tracker with IP65 waterproof and can be used for cars and motorcycles. The tracker device’s GPS sensor supports all kinds of functions, such as engine shutdown and restore, geo-fencing, ACC ignition detection, and internal storage for no GSM zones. With enough factory testing and worldwide customer feedback, the unit is user friendly, durable and reliable.

Tracking Device GPS Sensor Specifications

Dimension	80 mm x 40 mm x 10 mm	Reading	41.6g
power input	9 –36 VCC	GPS chipset	MT 3336
operating humidity	5% to 95%	Operating temperature	-20°C to +85°C
GSM frequency	850/900/1800/1900 MHz	GPRS	Class 12, TCP/IP
GPS sensitivity	-165 dB	Acquisition Sensitivity	-148dBm
Positioning accuracy	10m	TTFF (open sky)	Avg. hot start ≤ 1s Avg. cold start ≤ 35s

Tracker Device GPS Sensor Features

1. GPS positioning and GPRS real-time location report to platform server

2. Real-time Tracking for Car/Truck/Motorcycle

3. Built-in high sensitivity GPS and GSM antenna

4. ACC ignition detection

5. Geo-fencing

6. External power disconnection alarm for anti-theft

7. Support engine shutdown and restore

8. AGPS helps positioning even in weak or no GPS area

9. Internal memory support 2000 GPS data storage and re-upload under any GSM area
